WPLSoft is a software which are developed For Delta DVP series PLC, Delta VFD and Delta HMI(see list supported VFD and HMI list below).In a WPLsoft you can easy connect Delta supported device with communication setting, delta WPLSOFT compatible with IEC standard.

in delta plc TMR is a timer instruction as we know timer is very important part in industrial automation. Delta PLC have 100 ms timer, 10 ms timer and 1 ms timer. these timer have specific range for example if we have ES/EX/EC Series CPU (EC3-8K not include) than range for 100ms timer is T0 to T63, 10 ms timer range is T64 to T126 and 1ms timer range T127.

In Delta Plc counter is a important instruction in PLC. in delta plc have two types of counter CNT is 16 bit Counter instruction. DCNTis 32 bit counter instruction. counter increment or decrement current value by 1 each time when input of counter is changed from OFF to ON.

Delta ISPSoft is the programming software used for programming of Delta PLC and VFD, especially the DVP and AS series. It allows users to write, simulate, and upload logic programs to the PLC. It supports five programming languages. They are ladder diagrams (LDs), sequential function charts (SFCs), function block diagrams (FBDs), instruction lists (ILs), and structured texts (STs). Users can use more than one programming language in one project. It supports the international standard IEC 61131-3 and a large number of applied instructions. This guide helps beginners understand how to initiate their first project in Delta ISPSoft and configure it for a specific PLC model.

A timer in a PLC is an instruction that allows the programmer to count time, typically starting from zero and incrementing the Present Value until it reaches a predefined Preset Value (S2). In Delta PLCs, timers are essential for time-based control operations and are available in both low-speed and high-speed types. In Delta PLCs, timers are essential for time-based control operations and are available in both low-speed and high-speed types. The time base (unit) of Delta PLC timers can be 1 ms (millisecond), 10 ms, 100 ms. for example If you use timer T0 with a Preset Value of 100, and T0 operates with a 100 ms time base, the timer will reach the set value after: 50 × 100 ms = 5000 ms = 5 secondsSo, the timer will count from 0 to 50 in 100 ms steps, totaling 5 seconds, and then activate the timer coil (T0). in this article we Learn how to use the Delta PLC Timer Instruction in Ladder Logic programming. Step-by-step examples and clear explanations for beginners and adva

Learn about Delta PLC address types like X, Y, M, D, T, C, and S. Understand input, output, memory, and timer device codes with examples.

Learn the difference between CNT (low-speed counter) and DCNT (high-speed counter) in Delta PLC using WPLSoft or ISPSoft. Explore practical use cases, device addressing, timing behavior, and application guidelines.

Learn how to use CNT and DCNT instructions in Delta AH Series PLCs. Understand the working of 16-bit and 32-bit counters, including counting direction, preset values, and auxiliary bit control for general-purpose and high-speed applications.
